Pretty ways for the use of zipper needle detector

Zipper is widely used in daily life, and you can see them everywhere. Jeans shorts in your closet and cotton thobe, boots and house shoes slippers with zipper design in shoe cabinet, the bulk pannier bag is in the back of off-road motorcycle  and some accessories on the bag all contain zippers. Zipper needle detector is a must in relvant industries.

Only when the zipper reaches the non-magnetic standard can it pass the security check. It is very important for the corresponding staff to grasp the relevant knowledge of the rules for the use of the needle detector and the judgment and troubleshooting methods of the common problems of the needle detector maintenance.

Purpose of zipper needle detector

The test item of the zipper needle detector is to ensure that the zipper product reaches the non-magnetic standard, so that the user's clothing can pass the needle detector inspection smoothly. In order to ensure the correct use of the needle detector for testing purposes, the following rules of use have been formulated.

Pretty ways for the use of zipper needle detector

1. Test range of needle detector

3#, 4#, 5#, 8# zippers, zipper pullers, metal front and rear yards, metal block bolts.

2. How to use the needle detector:

After turning on the power of the needle detector, adjust the operation display to position B.

When the needle detector conveyor belt is running, the test small steel ball (test card) must be tested first, and the product test can be carried out after confirming that the needle detector is normal.

In the process of testing the product, it should be put up one by one or one by one, and it is not allowed to put up one by one. If there is a chirping sound, it means there is magnetism, and if there is no chirping sound, it means there is no magnetism.

When there is a beeping sound, the machine will automatically stop. At this time, the product under test should be removed, and the standby device should run again for 5 seconds before performing normal operation.

Note that when using, make sure that there is no magnetic source around, no vibration, and no magnetic source on the tester's body.

3. Testers

Carry out fixed-post and fixed-person operations.

4. Test record

After the test, the tester records and saves the test results, and signs on the warehouse records.

5. Test requirements: (the degaussing zipper indicated on the computer list)

Each copper zipper must be tested. Each slider must be tested.

6. The test is complete

After each test is completed, clean the machine and turn off the power of the machine.

Judgment and troubleshooting of common problems in needle detector maintenance

When the needle detector machinery malfunctions during use, sometimes it is not necessary to seek a professional repairer. In most cases, the problem can be resolved by itself. The following are the judgments and troubleshooting methods of some common problems of the needle detector.

Why does the needle detector react to the iron content in the conveyor belt, and the conveyor belt does not stop when the product is running?

The needle detector is equipped with a sensor that detects whether there is a broken needle and a photoelectric sensor that detects whether there is a product. When the needle detector is in normal operation, the photoelectric sensor controls the operation of the conveyor belt. In other words, when the photoelectric sensor does not sense the product (there is no product placed on the conveyor belt), the conveyor belt will not stop even if the needle detector responds.

The photoelectric sensors are arranged on both sides of the conveyor belt with a height of about 5 mm. If the thickness of the detected product is very small (for example, 4 mm or less), the product will pass under the sensor beam and it is impossible to confirm whether there is a product, so the conveyor belt will not stop even if the needle detector responds.

In fact, the thickness of the product is generally about 7 mm no matter how thin it is. It can be said that the photoelectric sensor can sense all the detected products. However, even if iron powder is stained on the conveyor belt, the conveyor belt does not stop due to the above reasons (the machine is set as a finished product). In mode C, the thickness of the product should be above 1.5 cm, otherwise it may cause sensor leakage, which is the so-called light leakage phenomenon).

Dirt on the conveyor belt of the needle detector causes the machine to malfunction

Performance

The indicator light on the probe flashes erraticly or the conveyor belt runs to a specific part and the alarm will go backwards. Also, if you put a piece of clothing without any metal, you will find that sometimes it passes through, and sometimes it cannot pass through the needle detector channel. .

Reason

The conveyor belt must be thoroughly cleaned every week. The surface of the conveyor belt is easy to get dirty because the products and factories are often placed on the surface of the dust, so it must be cleaned regularly. Especially the back of the conveyor belt must remember to clean, usually many people only know to clean the surface of the conveyor belt, but ignore the cleaning of the back. During daily use, dirt containing trace amounts of iron may be attached. If this kind of dirt accumulates, even if the needle is not broken during IEC 60794-4 the detection process, it will react to the dirt on the conveyor belt and cause the machine to malfunction.

Solution

Use a clean towel dampened with water and wrung out to wipe the surface of the conveyor belt and wear it to the back to wipe. Until the probe indicator will no longer flash after starting up and running.

When dirt on the conveyor belt is detected, the needle position detection indicator on the mechanical operation panel will light up. When the conveyor belt is rotating, the iron powder on the conveyor belt will be fixed on the same part of the conveyor belt to light up to show that foreign objects have been detected. At this time, only the conveyor belt can be cleaned to eliminate the fault.

In addition, manufacturers specializing in the production of metal detectors and needle detectors remind you that some plush holiday gnomes are designed to be worn with straps For zippered clothes, please use textiles metal detector after checking for broken needles, please don’t forget to use zipper needle detector.
