Heavy weight automatic checkweigher for pharmaceuticals, daily chemicals, food, chemicals, batteries, hardware accessories
Quick Details
Product Code：
SACW-600KG
OEM：
Available
Sample:
Available
Port:
Shenzhen
Payment:
Western Union,T/T
Place of Origin：
China
Supply Ability：
50 unit per month
Quick Details
Shipping fee
Shipping fee
Heavy weight automatic checkweigher for pharmaceuticals, daily chemicals,chemicals, batteries, hardware accessories
| Model | SACW-600KG |
|---|---|
| Power supply | Power supply: single-phase AC200V~240V (110V/380V can be customized) |
| Rated power | 0.8KW |
| Single weighing range | 30～30000g |
| Highest sorting accuracy | ±15g |
| Resolution | 0.5/1g |
| Belt speed | MAX.40m/min, throughput MAX.35 times/min. |
| Belt size | 700mm*500mm (length * width) |
| Height of belt surface from ground | 500~1000mm |
| Overall size | Length * width 2000*1500*1350mm |
| Monitor | 10-inch color touch screen |
| Elimination method | Push rod type sliding type optional |
| Control System | High-speed A/D sampling controller |
| Preset product number | 99 |
| Conveying direction | Facing the machine, left in and right out |
| Working environment | Temperature: -5℃～40℃, humidity: 30%～95% |
| Body material | Stainless steel 304 polished |
| Operation screen display | Chinese, English, Turkish, Spanish, etc. |
| Other standard equipment | Windshield (colorless and transparent), calibration weight |
| Combination machine | Printers, printers, labeling machines, metal detectors, etc. |
| Protection level | Protection level conforms to IP-65 international standard |
| Remarks | According to the different dimensions of the tested product and the working environment in which the equipment is running, the accuracy of the speedometer is slightly different |
1 10-inch color touch screen; like a smart phone, easy to operate.
2 Simple operation: using Weilun color man-machine interface, fully intelligent and humanized design;
3 Language selection: friendly operation and display language, the operation interface can be switched between Chinese and English
4 Up to 10-200 shortcut menus, seamless docking and changing products, realizing non-stop changing products.
5 Zero tracking: can be manually or automatically cleared, and dynamic zero tracking;
6 Report function: built-in report statistics, the report can be generated in EXCEL format, can automatically generate a variety of real-time data reports, the U disk can store statistical data for more than one year, and support the production status at any time
7 Provide feedback signals on production trends, adjust the packaging accuracy of upstream packaging machines, improve user satisfaction and reduce costs.
8 Air-blowing rejection device, to prevent the product from being rejected 100%, add two air nozzles for confirmation, to ensure the integrity of the test object, and to make different rejection methods for different products.
9 Interface function: Reserve a standard interface, which is convenient for data management, and can communicate with PC and other smart devices.
10 Adjustable speed: the motor is controlled by frequency conversion, and the speed can be adjusted as required;
11 High-speed and high-precision: high-precision digital sensors are used, with fast sampling speed and high precision.
The automatic weighing and sorting equipment is a high-speed, high-precision online checkweighing equipment, which can be integrated with various packaging production lines and conveying systems. It is mainly used for online inspection of product weights and whether there are missing parts or instructions in the packaging. Also known as: underweight detector, weight sorting machine, weight sorting machine, rechecking machine, automatic weighing machine, weight sorting machine, checkweigher. It can be widely used in pharmaceutical, daily chemical, food, chemical, battery, hardware accessories, electronics, plastic and other industries.
| Shanan Heavy weight automatic checkweigher for pharmaceuticals, daily chemicals,chemicals, batteries, hardware accessories.is R&D and production of detectors,specializing in Industrial Metal Detector instruments,provide public security inspections. Tailor-made solutions for customers.to protect customer brand image and improve customer productivity and production quality. |
|---|
